Making of "Marooned"

Saeed Amiri 2016-06-06 09:35 tutorial  > 3ds MAX  > modeling

Saeed Amiri explains how he created moody alley in 3ds Max and ZBrush.

This is a tutorial by Saeed Amiri. Visit his page on Behance: Visit his page on Behance: www.behance.net/saeedamiri

Click on image to enlargeFig00_evermotion.jpg

My main inspiration was Julien Coquentin's photos and I’ve also used some other photos as inspiration.





Modeling

Click on image to enlargeFig01_evermotion.jpg

I used Debris Maker for blocks. I modeled cement mortar with simple polymodeling which is decimated and unwrapped in Z-brush with Decimation Master and UV Master.



I used Wire Fence Script to model the fence. The Road is a long plane which has 10x10x2 FFD box modifier to controll it’s tilt and bend.

Click on image to enlargeFig02_part_01_evermotion.jpg

I used SpeedTree to model the trees.



Click on image to enlargeFig02_part_02_evermotion.jpg

I modeled only one tree and then used Export Variations for making 5 different trees in one style.



I used Z-brush deformation tools to create stone wall. This was my workflow:

Click on image to enlargeFig03_part_01_evermotion.jpg

First, you need to have a lowpoly and unwrapped geometry of your wall



Click on image to enlargeFig03_part_02_evermotion.jpg

Export your model as .obj file and now it’s ready for Z-brush.



Click on image to enlargeFig03_part_03_evermotion.jpg

Before importing into Z-brush you need an alpha texture of stone wall which you will use as a mask in Z-brush.



Click on image to enlargeFig03_part_04_evermotion.jpg

Import .obj file into Z-brush and subdivide mesh more than once, load your texture as alpha then go to masking section and use Mask by Alpha, Then use deformation tools to give displacement to your mesh (I used Inflate & Inflate Balloon), After that you can sculpt small details on your wall, At the end use Decimation Master plugin and decrease your mesh poly count.  My final result above.



Click on image to enlargeFig04_evermotion.jpg

I also used Z-brush’s Clay brush for adding the details



Click on image to enlargeFig05_evermotion.jpg

The rest of my models.



Click on image to enlargeFig06_evermotion.jpg

Objects were distributed by Advanced Painter.



Click on image to enlargeFig07_evermotion.jpg

That will be enough for the modeling, now we can move on lighting setup, but before that, I want to show you the viewport with all models.



Click on image to enlargeFig08_part01_evermotion.jpg

I used Dome Light with an HDRI from VIZ-Park to lit the scene. I desaturated this map and used standard direct light for simulating sky light with poor sun light.



Click on image to enlargeFig08_part02_evermotion.jpg

I used standard target light to lit the interior.



Materials

I always used composite and another blend tools to create materials. Most of the textures were downloaded from texturepilot.com and textures.com, for clean UVW I always had unwrapped geometries. Some materials tips:

  • The road: I used Vray Blend as the main material for mixing soil and asphalt material together

Click on image to enlargeFig09_part_01_evermotion.jpg

Asphalt material



Click on image to enlargeFig09_part_02_evermotion.jpg

Soil Material



Click on image to enlargeFig09_part_03_evermotion.jpg

They were blended with this texture which I had created in Photoshop.



Click on image to enlargeFig09_part_04_evermotion.jpg

And this is the final result.



Click on image to enlargeFig10_evermotion.jpg

Wood Material



Click on image to enlargeFig11_evermotion.jpg

Door Metal



Click on image to enlargeFig12_evermotion.jpg

Render Settings. I always used Progressive Image Sampler with zero noise and render time, usually I stop the rendering by myself when everything is looking good but in some cases with tight deadline I set a render time.


Post production

Here is a post-production process with Photoshop and Magic Bullet, Nik Correction plugins.



Here is the result and thanks for reading.

Click on image to enlargeCamera1Final_evermotion.jpg

Final result. camera 1.



Click on image to enlargeCamera2Final.jpg_evermotion.jpg

Final result. camera 2.



Click on image to enlargeCamera3Final_evermotion.jpg

Final result. camera 3.



Click on image to enlargeCamera4Final_evermotion.jpg

Final result. camera 4.



Click on image to enlargeCamera5Final_evermotion.jpg

Final result. camera 5.


Visit my page on Behance: www.behance.net/saeedamiri


Author: Saeed Amiri Editor: Michał Franczak
