Lost in the garden

Federico Ciavarella 2014-04-22 09:52 tutorial  > 3ds MAX  > modeling

Tutorial by Federico Ciavarella for 3ds Max / V-Ray users.

Hi everyone! My name is Federico Ciavarella, I’m an Italian Architect and a freelance 3D visualizer. Before beginning, I have to thank Evermotion for this great opportunity and I also have to credit Alex Roman and his book "From bits to the lens" that was essential for the vegetation that I created for this work.

Software used: 3ds Max, Vray, Photoshop, Marvelous Designer and Zbrush.

Final Images:

Click to enlarge imageV1_Garden_nr.jpg

Final image - garden





Click to enlarge imageV2_Dining_nr.jpg

Final image - dining room



Click to enlarge imageV3_Kitchen_nr.jpg

Final image - kitchen



Click to enlarge imageV4_Reading_nr.jpg

Final image - reading room



Click to enlarge imageV5_Bed_nr.jpg

Final image - bedroom



Click to enlarge imageV6_Bath_nr.jpg

Final image - bath



Click to enlarge imageV7_Garden_Wireframe_nr.jpg

Garden - wireframe





Concept

Basically, I started this work to test some of the vegetation tips I found in "From bits to Lens" book by Alex Roman, which is an excellent reading for 3d visualization artists. The house, instead, was inspired by a Villa found on "Elle Decor Magazine - Italia" that in some way reminds me the Farnsworth House by Mies van der Rohe or the Glass House by Philip Johnson, but at the end I tried to create something personal and not just a copy. Let’s start!

Vegetation

Following the Alex Roman’s tips, I started with a plane, I applied the texture and then I added the subdivision to follow the shape of the leaf. This is useful, because opacity maps require lot of calculation time. If you leave only a few parts in ‘black’ the calculation time is acceptable and the leaf still maintains the fractal natural form.

Click to enlarge imageImage_1_nr.jpg

Modeling a leaf



Click to enlarge imageImage_2_nr.jpg

I made this procedure both for leaves and roses petals.



After testing some specific software to create trees, I realized that, for my needs, the best solution was the most simple one. Branches and trunk are mostly hidden, so I modeled them by hand.

Click to enlarge imageImage_3_nr.jpg

Making branches



I unwrapped them with Xray Unwrap plugin.This was very tedious but at the end I modelled only 2-3 branches and 1 trunk for the trees, and then I added symmetry modifier. Thanks to Multiscatter, I could get a lot of variations of bush structures that was made from just one model. All the leaves were scattered with this plugin and once I found a good setting it was very easy to change seeds and obtain different configuration of trees and bushes. Multiscatter was also used to place branches on the tree trunk, before scattering the leaves.

The other advantage of this method is that if the leaves and the branches have a noise rotation before scattering, it’s possible to achieve the ‘wind effect’ for animations.

Click to enlarge imageImage_4_nr.jpg

Multiscatter - branches and leaves



For the distribution I used Vertex Paint. In the future I’ll probably also use another good tip from Alex Roman - I will customize pre-made trees, available in collections such as those by Evermotion, to avoid the tedious process of creating the structure of the trees. In my opinion on what really worths to be customized: the leaves and the roughness of the bark (if visible).

Materials

Click on image to enlargeImage_5_nr.jpg

Materials



Click on image to enlargeImage_6_nr.jpg

Materials



To optimize rendering time I increased cutoff of the tree leaf material to 0,1 for all trees that are far from the camera.

Click on image to enlargeImage_7_nr.jpg

Materials



Modeling

Nothing special to say here, Just a couple of things that someone can possibly find useful.

Click on image to enlargeImage_8_nr.jpg

Wooden floor



Click on image to enlargeImage_9_nr.jpg

Cloth



Lighting

For exterior and Interior light I used HDR skies inside of a Vray Dome light. The skies are completely desaturated with color correction inside 3ds Max, this is a thing that I usually do for the 90% of the interior images and rarely for the exterior. The gamma was left mostly at 1, some images have it at 0,9, this is because the skies in this scene are overcasted. I usually decrease it at about 0,8 / 0,75 with other types of skies. Skies used: 1044, 0902, 1008 by Peter Guthrie.

Click on image to enlargeImage_10_nr.jpg

HDR skies



I added two Vray planes to give an extra touch to the homogeneity of the light. Similar settings were used for the other images, with or without extra Vray planes.

Click on image to enlargeImage_11_nr.jpg

HDR skies



The Vray sphere was put inside the filament to avoid the ‘too perfect’ effect.

Click on image to enlargeImage_12_nr.jpg

Lighting



Render settings

Click on image to enlargeImage_13_noresize.jpg

Render settings



Post production

The post production was very fast. As a lover of photorealistic rendering I tend to treat raw renderings as photographer treat raw photos. I start with Magic Bullet Photolooks to work at 32 bit and after I use common Photoshop tools included Photoshop Camera Raw (especially now that it has an easy access from the filter menu) mainly to check overexposed area, have an easy control of individual colors and to use the noise reduction tool.

Click on image to enlargeImage_14_nr.jpg

Raw render vs. post production



Click on image to enlargeImage_15_nr.jpg

White Balance doesn’t need to be perfect but I always prefer to check it in this kind of images.



Click on image to enlargeImage_16_nr.jpg

Post production in Magic Bullet Photo Looks



Click on image to enlargeImage_17_nr.jpg

Photoshop Camera Raw, check the overexposed areas.



Click on image to enlargeImage_18_nr.jpg

Photoshop Camera Raw, noise reduction is better to be only in specific areas, as we don't want to lose details.





That’s it! Thanks for reading, I hope you can find it useful. For any clarification you can write me here, or on my Facebook and Behance page. Cheers!

Federico Ciavarella

Author: Federico Ciavarella Editor: Michał Franczak
Tags: garden 3dsmax v-ray lostinthe Federico Ciavarella
