Octane render review

In the field of rendering, it all probably begun at Siggraph 2008 (or 2009?) when Chaos Group presented their first shots of GPU rendering with new Vray version being worked on. Soon after that, many other GPU based renderers started to appear, and now many of common and vell developed CPU physically based rendering engines, try to find their sollutions in GPU computing. Why is it becoming so? Well, we may quote form NVidia website: "GPU computing is the use of a GPU (graphics processing unit) to do general purpose scientific and engineering computing.







The model for GPU computing is to use a CPU and GPU together in a heterogeneous computing model. The sequential part of the application runs on the CPU and the computationally-intensive part runs on the GPU. From the user's perspective, the application just runs faster because it is using the high-performance of the GPU to boost performance." Why do I quote NVidia information and not for the example ATI? Because Octane Renderer which is the subject of this review, currently uses only NVidia's GPU CUDA technology, that allows us rendering on our GPU Card. At the moment it's much more efficient than OpenCL technology, which would allow us rendering on ATI graphics cards, but maybe someday it changes. We woun't be getting into many details here. Right now most developed GPU renderers use NVidia's CUDA technology only.





Ok so let's begin with Octane. Firstly, some information from the developer's website (www.refractivesoftware.com): "Octane Render is the world's first GPU based, un-biased, physically based renderer. What does that mean? It uses the video card in your computer to render photorealistic results fast...really fast. This allows the user to create stunning works in a fraction of the time of traditional CPU based renderers." Let's point some basic info about the renderer. Octane unlike many other 3D applications is very cheap and avaiable to even common user of graphics software. It costs only 99 euros in present beta state (and was even 50% cheaper for some time), which makes it really competitive amongst all the other rendering engines. And everyday growing gallery is probably the best proof, that the small price doesn't mean poor quality. (https://www.refractivesoftware.com/gallery.html)



(Artwork made by Artur Szymczak)

(Artwork made by Andrian)

(Artwork made by Christophe Desse)

The other interesting thing is multi-platform support, so we can run Octane under MS Windows, Apple Mac or even Linux! We are also not bound to any 3D software, because Octane works as standalone renderer. With currently developed plugins, we can link it to the most popular applications such as: Autodesk 3ds Max, Maya, Softimage XSI, Maxon Cinema4D, but also to Blender, Google SketchUp and Luxology Modo. Even more, if we work for example in any 3D CAD application such as ArchiCAD, we can export our model/scene to Wavefont .obj format, and then import it to Octane for material seup and rendering process. That is a very suitable solution for many studios or single users, because final output from 3D application needed in Octane, is just an .obj written file, which nowadays can be produced by almost every available 3D software. I think that's all about basic information, we'll now move to more technical stuff. It just needs to be mentioned that Refractive Software also provides a DEMO verion of Octane Render which can be downloaded here (https://www.refractivesoftware.com/downloads.html), so You might give it a try and make Your own tests. Just be sure You have at least + GT8800 NVidia graphics card and latest CUDA drivers. You can check if Your hardware is compatible with CUDA technology by visiting this website (https://cuda-z.sourceforge.net/) and running the utility. Octane is currently in Beta state, but that doesn't make it useless or unstable at all. I might list all the already available features, but they can be found under this link https://www.refractivesoftware.com/features.html , so I'll focus only on the most important of them.

Octane's working area is divided into 3 sections - Viewport, Graph Editor and Node Inspector.





As Octane is real-time renderer, each change is beeing automaticaly displayed in the viewport, so we have constant preview of how our final scene would look like. Everything is being done "on the fly", there's no need of time consuming, stopping and restarting processes like in normal CPU renderers - with an average GPU unit sometimes it takes just a few seconds, to have nice, clean render.

One cool and really interesting thing in Octane is ability to render stereoscopic images also in full real time! I personaly was very sceptic about all the 3d stuff that appeared lately, but believe me - Octane has really changed my mind. It's really a brand new experience to navigate your scene and have a real time preview in 3D.



The other panel is Graph Editor. It's directly linked to Node Inspector, and by using these two areas we can setup our materials, environment settings, camera etc. If you have used Blender or Autodesk Maya, you should be familiar with this type of workflow. Otherwise it would just take you a few moments to get used to i., Nodes are very intuitive way of setting up your scene parameters.



(Graph Editor)

(Node Inspector)

Now we'll roughly look at the Octane's materials. We have 3 basic shaders to choose from - diffuse, glossy and specular. It's quite different approach to material setup than in "classic" un-baised physical renderers like Indigo or Fryrender, where you can adjust your settings using layers manager. Here each shader has it's own parameters such as specularity, roughness, opacity etc. and many operators to control them. For example, in specular shader which produces glass material, one can put "gaussianspectrum" operator as a transmission controller, which gives really interesting results. Also, by creating a node setup in Graph Editor and joining diffuse shader with RGB Spectrum operator as a transmission controller, we can produce a translucent material. It may sound a bit complicated, but real time preview gives us much better opportunities to see the changes we make and adjust everything exactly like we want to.



(An example of setting up translucent material. To see the effect, pathtracing must be turned on.)

(Example render)

Now let's see camera setup. Currently in beta stage, Octane offers only normal, perspective camera with adjustable field of view and aparature size. Lighting tweaks such as ISO value, fstop or camera filters can be applied on the fly without the need of rerendeing the scene. They can be adjusted even after the rendering has finished. But probably one of the most interesting features is real time DOF adjustment. All we have to do is just to choose a "picker" in the viewport panel and click the object we would like to focus our camera on. This makes rendering process much more like playing a 3D photography than standard working with models and scenes.
